Detailed
CTP(.to.)is the editing or pages to the edition of the CPS(CEPS)or CDS(DTP)in the CPS. It's the the CPS, the CPS, the CPS, the CPS, the CPS, the CPS, the CPS, the CPS, and DTP, the CPS, the CPS, the CPS, the CPS, and DTP, the CPS, the CPS, the
It's the example to the example, the 2011-4-27d to the the example 238, the example in the content in the content of the content, the環(huán)境污染, the環(huán)境污染, and the law in the content to the content to the content, the the content to the content to the content to the content to the the the the content to the the the content.A. SpecialEnvironments is be be be be be be be be be be be be be be be be be be be be be be be be be be be be be be be be be be be be the the name, the the the the the name, the the the the name, the the the the the name, the the the the the example of the the the example.
CTP TouthDealStimeDouthOffice。
Based on the above pain points, MSA hired a famous Taiwanese sewage treatment expert, Mr. David Chen, to jointly develop a CTP wastewater recycling treatment machine in 2017. After more than a year's efforts and efforts of all partners, MSA has successfully developed the CTP wastewater recycling treatment machine, and obtained the invention and new practical patent (acceptance number). The developer and flushing board water can be reused by CTP waste water recycling treatment machine, and the discharge amount is greatly reduced (collectible - > recycled).
The end of direct emissions is in line with the era of green printing. ..
Technical features of CTP wastewater recycling processor:
1. A high-power filter circulating system is connected in parallel with the original filter pipes in the printer, which has no influence on the original circulating filter. The system can effectively remove impurities, crystals, colloids, etc. in the developer, and increase the circulation of the developer and remove micro particles, oils and colloids in the developer.
2. Realize the standard state of the developer, stabilize the plate-making effect, greatly reduce the crystal precipitation of the developer trough, and the developer basically has no suspended solids. It greatly reduces the crystallization of developing cots and brushes, avoids the physical scratches on the plate, reduces the loss of paper, ink and manual shutdown caused by plate faults, reduces the times of washing machine and improves the production efficiency.
3, prolong the service life of developer solution by more than 2 times. It can save the cost of developing effluent and the discharge of waste liquid, prevent the blockage of the pipeline of the developer, improve the processing capacity of the developer, reduce the pollution and treatment cost caused by the discharge of waste liquid by manual cleaning, and prolong the service life of the developer.
4. Reducing the discharge of developing waste liquid to meet the requirements of green printing, fully in line with the state's provisions to promote green printing energy saving and emission reduction.
5, pressure gauge alarm reminder function, accurately remind consumables replacement time, convenient maintenance.
6. Water-washing and filtration connect the original water-washing trough drainage system of the plate-making machine. The plate-making water is recycled by means of physical filtration and chemical reagent automatic replenishment, neutralization, flocculation, filtration, decolorization, deodorization, sterilization, and deep-seated filtration. The stable and clean plate-washing water is provided for the plate-making machine through professional high-power professional pump. Circulating water should be discharged automatically and regularly according to the environmental protection discharge index, which not only realizes the recycling and utilization of washing water and saves energy, but also ensures that the discharged water meets the national level 2 water discharge standard without pollution and environmental protection. The water consumption of 1200-1500 plates is 12 tons and 15 tons, and the water consumption after treatment with this equipment is 100 L, which greatly saves water consumption and wastewater discharge of enterprises. At the same time, the equipment has its own buffer tank, which can avoid the damage caused by the sediment in tap water to the printing plate surface, and the production loss caused by water cut-off, and improve the production efficiency.
7. Professional water tank design ensures the quality of plate-making water, realizes the standardization of plate-making water, stabilizes the effect of plate-washing, ensures the clean and clean layout, improves the quality of plate-making, and conserves energy and environmental protection.
8, save more than 95% of the water consumption of the enterprise, save the cost for the enterprise, and achieve green printing.
9, PLC operation control, interface content is clear at a glance, data set is convenient and simple, stable use.
About after sale:
One year warranty, life-long maintenance (except for vulnerable parts)
In order to create a famous brand enterprise, improve its popularity and establish its image, we sincerely promise to you on the principle of "the most favorable price, the most considerate service and the most reliable product quality" in the spirit of "all pursuit of high quality and customer satisfaction".
First, product quality commitment:
1, quality inspection and testing data are available for manufacturing and testing of products.
2. To test the performance of the product, we invite the user to check the whole process and all-performance of the product personally, and then pack the product and ship it after it is confirmed to be qualified.
Two, product price commitment:
1. In order to ensure the high reliability and advanced nature of the products, the components are selected domestic or international high-quality brand products.
2. Under the same competitive conditions, our company will offer you the most favorable price sincerely on the basis of not reducing the technical performance of the products and changing the components of the products.
